Mindray Passport 12 Patient Monitor

Description

Mindray Passport 12 Patient Monitor: Overview and Features

The Mindray Passport 12 Patient Monitor exemplifies Mindray’s commitment to innovation and quality in healthcare technology. Offering a blend of advanced monitoring functions, user-friendly design, and seamless integration capabilities, it represents an invaluable tool for enhancing patient care and operational efficiency in medical facilities worldwide.

Comprehensive and Advanced Monitoring

• Wide Range of Parameters: Equipped to monitor vital signs including ECG, NIBP, SpO2, respiratory rate, temperature, with options for invasive blood pressure (IBP) and CO2 measurements, ensuring a holistic view of the patient’s physiological status.
• Critical Insights: Delivers accurate, detailed patient data crucial for the effective management of critically ill patients, supporting timely clinical interventions.

Designed for Enhanced Usability

• High-Resolution Touchscreen Display: Features a 12-inch color touchscreen display, offering clear visualization of patient data and trends for easy interpretation.
• Customizable Interface: Allows clinicians to tailor the display layout to their specific monitoring needs, enhancing data accessibility and streamlining workflow.
• Intuitive Operation: Simplified navigation and quick-access controls enable easy adjustment of settings and parameters, facilitating efficient monitoring processes.

Seamless Integration and Efficient Workflow

• Robust Connectivity: Advanced networking capabilities ensure smooth integration with Electronic Medical Records (EMR) and hospital information systems (HIS), facilitating seamless patient data management.
• Workflow Optimization: Enhances documentation accuracy and supports efficient patient care coordination across departments, contributing to improved clinical outcomes.

Built for Durability and Versatility

• Rugged Construction: Engineered to withstand the demands of various healthcare environments, ensuring reliability and longevity.
• Flexible Application: Portable design and battery operation option make it suitable for a wide range of clinical scenarios, ensuring continuous patient monitoring.

Specifications

Dimensions:

• Size: 12.2″ x 11.4″ x 6.7″ (31.0 cm x 28.9 cm x 16.9 cm)
• Weight: 10.6 lb (4.8 Kg)

Power Requirements:

• Line Voltage: 100 to 240 VAC (± 10 %)
• Maximum Current: 2.0 A.
• Frequency: 50/60 Hz (± 3 Hz)
• Battery: Rechargeable lithium-ion battery, 4500mAh. ≥ 4 hours run time
• Recharge Time (Power Off): 5 hours to 90%

Environmental Requirements:

• Temperature
  • Operating: 0 to 40 °C (without AG and CO₂ module). 10 to 40 °C (with AG and CO₂ module)
  • Storage: -20 to 60 °C
• Humidity
  • Operating: 15 to 95 % (non condensing)
  • Storage: 10 to 95 % (non condensing)
• Barometric
  • Operating: 427.5 to 805.5 mmHg (57.0 to 107.4 kPa without AG and CO2 module)
  • Storage: 120 to 805.5 mmHg (16.0 to 107.4 kPa without AG and CO2 module)

Interfacing:

• Main Unit: AC power connector (1), VGA port (1), USB 2.0 connector (2), Analog output/nurse call/defib. Sync/Serial Port (1), Integrated module rack (1), for 2 slots
• Barcode Scanner: Supports 1D and 2D barcode
• Thermal Recorder: 3 traces (paper 50 mm width, 20 m length)
• Network Printer: Support
